Commercial Flake Ice Maker - 1000 KG/Day Portable Snowflake Ice Making Machine

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Yixing ICS
Certification:	ce

Payment & Shipping Terms:

Minimum Order Quantity:	1 - 2 Sets
Price:	$6,900.00
Packaging Details:	Wood cases in standard container or less than container loadEach set is wrapped in plywood case and transport in standard container
Supply Ability:	10 Set/Sets per Month

Contact Now

All Products

Flake Ice Maker Machine (75)

Block Ice Maker Machine (63)

Ice Tube Maker Machine (13)

Slurry Ice Machine (18)

Artificial Snowfall Machine (15)

Evaporative Condenser Chiller (11)

Cooler Refrigeration Units (12)

Aluminum Refrigeration Row (5)

Solar Power Containerized Cold Room (11)

Cold Storage Refrigeration Units (2)

Detailed Product Description

Ice Shape:	Flake Ice	Ice Storage Capacity:	1000KG
Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, A	After Warranty Service:	Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location:	None	Showroom Location:	None
Condition:	New	Voltage:	220V/380V(customized)
Power:	4.2 Kw	Dimension(LWH):	1207478 Mm
Weight:	380 Kg	Warranty:	1 Year
After-sales Service Provided:	Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support	Key Selling Points:	Automatic
Machinery Test Report:	Provided	Video Outgoing-inspection:	Provided
Marketing Type:	Ordinary Product	Warranty Of Core Components:	1 Year
Core Components:	Pressure Vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC	Product Name:	Flake Ice Machine
Name:	Snowflake Ice Maker	Keyword:	Flake Ice Machine Flake Ice Machine
Type:	Automatic Flake Ice Machine	Application:	Food Fresh Keeping
Cooling Way:	Air Water Evaporater Cooling	Compressor:	Bitzer
Material:	Stainless Steel 304	Refrigerant:	R404a/R22a
Ice Size:	Irregular Size	Port:	Shanghai

Product Description

Flake Ice machine

Yixing ICS fresh water flake ice machine is widely used in food processing, fruit and vegetables preservation, meat processing, medical research and etc. Seawater flake ice machine is designed for large ocean-going fishing industry which could overcome the corrosion of seawater, pitching and swing problems of vessels. Flake ice is a kind of irregular ice with size about 40*40 mm and

thickness around 1-2 mm. The thin ice can be directly used for stirring and mixing refrigerated materials. Besides, flake ice has no acute edges and corners so it will not damage the surface of cooled object. With large contact area and fast cooling speed, flake ice can realize high efficiency cooling effects.

Flake Ice Machine Evaporator

The internal structure of the evaporator is specially designed to improve heat-exchange efficiency and to keep the loop unblocked with special processing technology. The internally scrapping ice making mode has been adopted, which reduces the loss of the energy and avoids leakage the refrigerant.

Specification of all types of Flake Ice Machine Yixing ICS Produces

Model	Daily Capacity	Electricity Consumption	Install Power	Operating Weight	Dimention
BYF-05	0.5T	2.56kw	2.2kw	208kg	1200740590mm
BYF-08	0.8T	4.43kw	2.8kw	235kg	1200740650mm
BYF-10	1T	5.16kw	4.2kw	380kg	1200740780mm
BYF-15	1.5T	7.72kw	5kw	450kg	15601200880mm
BYF-20	2T	11.17kw	6.5kw	480kg	15601200960mm
BYF-25	2.5T	12.62kw	8kw	550kg	165012001150mm
BYF-30	3T	14.35kw	10kw	680kg	156012001150mm
BYF-50	5T	17.72kw	22kw	1250kg	220010501550mm
BYF-80	8T	25.55kw	30kw	1800kg	340015501800mm
BYF-100	10T	34.31kw	42kw	2200kg	355015502050mm
BYF-120	12T	38.8kw	55kw	3000kg	372016502050mm
BYF-150	15T	49.35kw	69kw	3600kg	400018502400mm
BYF-200	20T	60.4kw	86kw	4200kg	420020002914mm
BYF-250	25T	78.85kw	110kw	5500kg	450020002450mm
BYF-300	30T	102.45kw	125kw	6800kg	520022003000mm
BYF-350	35T	115.35kw	140kw	7600kg	520022003200mm
BYF-400	40T	147.35kw	180kw	8900kg	560024003600mm
BYF-500	50T	176.3kw	220kw	9800kg	580025004500mm
BYF-600	60T	214.9kw	280kw	10500kg	640025004500mm

Detailed Images

1) Internally-scraping ice skate can help reduce energy consumption and prevent leakage of refrigerant.
2) stainless steel materials, advanced processing equipment and heat treatment processing ensure the best heat transfer
efficiency.

3) The design of large water receiving plate can prevent water leaking at the bottom of evaporator.

4) Direct liquid feeding and dry evaporation, simple and safe to control.
5) Integrated modular design, convenient to install and maintain.

6) Flake ice is easy to crush and mold, with almost zero damage to the cooled products.

7)The internal structure of the evaporator is specially designed to improve the heat-exchange efficiency and to keep the loop
unblocked with special processing technology.

8)The internally scraping ice making mode has been adopted, which reduces the loss of energy and avoids the leakage of refrigerant.

Standard export packing

Wood cases in standard container or less than container load

Each set is wrapped in plywood case and transport in standard container

Our Services

Pre-sale service

* Inquiry and consulting support
* Sample testing support
* View our Factory

After-sale service

* Training how to install the machine, training how to use the machine
* Engineers available to service machinery overseas

Company Introduction

Yixing city Ice Source Refrigeration Equipment Limited is a comprehensive modern manufacture of all kinds ice making plants, cold room, high-efficiency cold air blower, energy-saving evaporative condenser, aluminum alloy pipe row and various civil constructions, combined with cold room engineering.

ICS is located in Yixing, Wuxi, Jiangsu, CHINA. With over 20 year's successful experience in Chinese market, we focus on the technical innovation to improve the machine quality and strengthen innovation ability. By insisting on the spirit "unity, seeking truth, pioneering and dedication", we commit ourselves to research and development of new technology, striving to create a comprehensive refrigeration enterprise in China.
